BLD932

L×W×H

6700x2100x3060mm

Rated bucket capacity

1.3m3

Rated load

3200kg

Maximum dump height

3100mm

Dump distance

1400mm

Wheel base

1640mm

Wheel tread

1850mm

Max. breakout force

48.8KN

Engine

Engine

Weichai Deutz

Type

In-line arrangement, direct injection, Water cooling, four-stroke

Rated power

92kw

Rated speed

2200r/min

Transmission  system

Model of torque converter

YJ280

Type

single grade three componets

Gearbox type

Fixed-spindle power shift

Gear shift

2 gears ahead,2 gear astern

Max  Driving speed

20-30km/h

Hydraulic system

Distribution of work valve

DF20.2C

Working pump

CBF18

Steering system

Type

Articulated hydraulic steering

Max. turning angle

35± 1°

Min turning radius(mm)

6000

Brake system

Brake type

Air assisted oil disc on four wheel

Tyres

Standard tyres

17.5-25
