BLD1500T

Specification	Overall weight(kg)	3400
	L×W×H（mm）	4860 x 1610 x2300
	rated bucket capacity(m³)	0.6
	Rated load(kg)	1500
	Max. dump height (mm)	2373
	Bucket indicator	Yes
	Wheel base (mm)	1800
	Thread (mm)	1140
	Max. breakout force(KN)	43
Engine	Model	Yanmar 4TNV86CT-PSY/Kubota V2403
	Type	In-line arrangement, Water cooling, four-stroke
	Rated power（kw）	35.5
	Rated speed(r/min)	2400
Hydrostatic system	Model	Italy PWG
	Motor type	MV80
	Gear shift	2 gears ahead,2 gear astern
Steering system	Type	Articulated hydraulic steering
	Max. turning angle	38±2°
	Min. turning radius(mm)	3172
Brake system	Brake type	Oil brake(Vacuum booster)
Tires	Standard tires	19.0/45-17
Standard bucket	Width (mm)	1650
