BLE18

Machine model

BLE18

Operating Weight

3968lbs/1800kg

Bucket Capacity/width

0.06m3/435mm width

Type of Tracks

Rubber track

Engine

Laidong 3TE25 3-cylinder /kubota

(Euro V/EPA)

Optional Configuration

Hydraulically retractable undercarriage

Export non-fumigation wooden box package

Swing boom

Radiator

OVERALL DIMENSIONS

A. Overall Length

3865mm

B. Overall Width

1050mm

C. Overall height

2270mm

D. Chassis width

1050mm

E. Upper chassis ground clearance

210mm

F. Cabin height

2270mm

WORKING RANGE

G. Max.Digging Height

3365mm

H. Max.Dumping Height

2385mm

I. Max.Digging Depth

2050mm

J. Max.Vertical Digging Depth

1725mm

K. Max.Digging Radius

3860mm

L. Min.Swing Radius

1720mm

M. Tail Swing Radius

1125mm
