BLE08

Operating Weight

800kg

Digging bucket capacity

0.02cbm/120kg

Maximum digging force

7.5Kn

Engine brand

KOOP/ Briggs & Stratton EPA

Rated power

7.0kw/3000r/min

Displacement

0.211 L

Main pump

single cylinder, fan cool

Valve

BEIFANG

Displacement

6.8ml/r

Swing motor

SJ-TECH (MP-1-160)

Traveling motor

KERSEN (OMS-2450)

Main Specifications

Overall dimension( LxWxH)

2480x720x1375 mm

Total length of track on land

1140mm

Platform ground clearance

80 mm

Platform back turning radius

784 mm

Chassis width

720mm

Track width

150 mm

Chassis ground clearance

132 mm

Track height

320 mm

Overall range

Max. Digging depth

1200 mm

Max. Vertical digging depth

1375 mm

Max. Digging height

2350mm

Max. Dumping height

1600 mm

Max. Digging radius on ground

2450 mm

Min. Rotation radius

1100 mm

Max. Upgrade height of bulldozer blade

120mm

Max. Digging depth of bulldozer blade

200 mm
